5. Adaption of class D amplifier to use the most efficiency of battery, and Type-C recharging method makes it much easier to recharge simply via a cell hone adapter or a portable battery without extra wall power adapter.
How to Use Guitar Function
1.Turn power ON, the indicator light is lit a color, which differs to different power level, 2.Link vour acoustic guitar by a cable to GUITAR INPUT socket. 3.Adjust Guitar Volume, Bass and Treble knobs and Master knob to get a suitable volume and tone output How to Use Mic Function 1.Link your moving coil microphone cable to MIC INPUT socket 2.Adiust Mic Volume knob and MASTER knob to get a comfortable volume,. 3.Adjust ECHO knob to get a satisfied echo effect.
Product Parameter
Channel 1 (guitar) Input socket: 6.35mm gauge jack x 1 Input impedance: 10Kohm EQ: bass, treble Volume control Channel2 (mic ) Input socket: 6.35mm gauge jack x 1 Input impedance: 1Kohm Echo control Volume control Battery: 7.4V / 2200mAH Li-battery Battery life: 2 5H (80% volume level) Recharge duration:< 3 H( 2A) Rated power: 10W Peak power: 15W Speaker: 5 inch, full range,20W x 1; Recharge socket: Type-C 5V-2A Specifications Net weight: 2.1kg Gross weight: 2.5kg Dimension: 21 5x156 5x153.5mm Package size: 262x200x205mm Package Contents: AG-15A amp, handle x1, Type-C cable x1, operation manual.
